Line 6 Helix Multi-effects Floor Processor

The Line 6 Helix multi-effects floorboard processor reaches far beyond anything you've ever experienced. It can be a great addition to your rig, a streamlined controller for your existing system, or an incredible-sounding guitar interface for recording in the studio — it can even replace your entire effects setup! Equipped with Line 6's new HX modeling engine, the Helix Floor will let you hear brand-new models of modern and vintage amps, cabs, mics, and effects — all designed to sound and feel just like the originals. And your rig-integration options are limitless with Helix's astoundingly comprehensive I/O and routing capabilities. Line 6 has long been at the forefront of the modeling revolution, and Helix is the professional guitar processor Line 6 was destined to create.

Features:

• Dual DSP-powered HX amp modeling engine
• Over 300 amp, cabs, mic, and effects models
• World-class polyphonic pitch-shifting effects
• 6.2-inch LCD display
• 12 touch-sensitive footswitches for editing
• 10 inputs, 12 outputs (including 4 effects loops)
• 8-in/8-out USB audio interface
• 3 expression pedal outs
• Mic-level XLR input
• S/PDIF, AES/EBU, and L6 Link digital outputs
• Capacitive touch-sensitive switches for parameter recall
• Assignable RGB LED color rings
• Customizable LCD scribble strips
• Preset or stompbox modes
• Integrated looper
• Solid-aluminum construction
• Tour-grade footswitches
• Supports third-party impulse responses (IRs)
• True preset spillover

Tech Specs:

• Pedal Type: Multi-FX
• Analog/Digital: Digital
• Presets: 1024 (8 setlists with 32 banks x 4 presets)
• Number of Effects: 200+ effects (Helix & Legacy combined, latest firmware), Up to 32 simultaneous FX (DSP permitting)
• Effects Types: Distortion, Delay, Reverb, Modulation, Pitch shift, Synth filter, Compressor/Limiter, Wah
• Amp Modeling: Over 100 Amp, Cab and Mic Models (latest firmware)
• Impulse Response: IR support
• Looper: 60 seconds (mono), 30 seconds (stereo) full speed
• Inputs: 1 x XLR (mic), 1 x 1/4" (guitar), 1 x 1/4" (aux), 4 x 1/4" (return)
• Outputs: 2 x XLR (L/mono,R), 2 x 1/4" (L/mono,R), 4 x 1/4" (send)
• Digital Inputs: 1 x Coax (S/PDIF). 1 x RJ45 (Variax)
• Digital Outputs: 1 x Coax (S/PDIF), 1 x XLR (AES/EBU, Link out)
• MIDI I/O: In, Out/Thru
• USB: 1 x Type B (8 x 8)
• Headphones: 1 x 1/4"
• Other I/O: 1 x 1/4" (control voltage), 1 x 1/4" (ext amp switch), 2 x 1/4" (expression 2/3)
• Expression Control: Built-in Pedal
• Features: 450MHz SHARC DSP Processor
• Compatibility: OS X 10.10 or later, Windows 7 SP1 or later
• Power Source: Standard IC AC cable (included)
• Height: 3.61"
• Width: 22.05"
• Depth: 11.87"
• Weight: 14.6 lbs.
